3' -10" American #396x153, Radial Arm Drill, 30-700 RPM, #4MT, S/N 684892A-1

(1) Used 3' x 10" AMERICAN Model 396x153 Radial Arm Drill; 700 R.P.M.; #4 M.T.; S/N 684892A-1
Specifications:
Column Diameter................................10"
Length of Arm..................................36"
Table Size.....................................27 11/16" x 21 7/8"
Base Size......................................31 7/8" L-R x 82" F-B
Base Type......................................T-Slotted Cast Iron
Spindle Taper..................................#4 M.T.
Quill Travel...................................12 3/8"
Variable Spindle Speeds (24)...................30-700 RPM
Travel of Head on Arm..........................24"
Vertical Travel of Arm.........................28" (nominal)
Distance Chuck Nose to Table Top...............
Table Working Area.............................
Distance Floor to Table Top....................
Centerline of Spindle to Post Collar Bracket...
Centerline of Spindle to Post..................11 1/2" - 45"
Column Post Collar Height......................
Motor..........................................U.S. Motors 3 HP
Electrical Characteristics.....................220/440 VAC / 3 Phase / 60 Cycle
Equipped With:
Complete Electric Controls
Power Feeds
Overall Dimensions.............................33" L-R x 100" F-B x 88" High
Weight.........................................4,000 lbs. (est.)
F.O.B..........................................Casa Grande, AZ
