For Sale by Yoder Machinery Sales
Surplus Record Dealer Since 1960
Sales
866-69...> Show Seller's Phone Number 866-692-8933 Let the seller know you found their listing on Surplus Record!
Description
SERIAL .................... 0713272150
MODEL ..................... SN71
SWING OVER WAYS ........... 28-1/2"
SWING IN GAP .............. 40"
SWING OVER CROSS SLIDE .... 16"
DISTANCE BETWEEN CENTERS .. 124"
LENGTH OF GAP ............. 16"
SPINDLE SPEEDS ........... 10 TO 1000 RPM
DIAMETER OF SPINDLE HOLE .. 3.15"
ENGLISH THREADS ........... YES
METRIC THREADS ............ YES
ENGLISH & METRIC FEEDS .... YES
TAPER ATTACHMENT .......... YES
4 WAY RAPID TRAVEL ........ YES
STEADY REST 3 POINT ....... 7 & 13"
MOTOR ..................... 10 HORSEPOWER
MODEL ..................... SN71
SWING OVER WAYS ........... 28-1/2"
SWING IN GAP .............. 40"
SWING OVER CROSS SLIDE .... 16"
DISTANCE BETWEEN CENTERS .. 124"
LENGTH OF GAP ............. 16"
SPINDLE SPEEDS ........... 10 TO 1000 RPM
DIAMETER OF SPINDLE HOLE .. 3.15"
ENGLISH THREADS ........... YES
METRIC THREADS ............ YES
ENGLISH & METRIC FEEDS .... YES
TAPER ATTACHMENT .......... YES
4 WAY RAPID TRAVEL ........ YES
STEADY REST 3 POINT ....... 7 & 13"
MOTOR ..................... 10 HORSEPOWER
Get Your Price from Yoder Machinery Sales!
