24 Ton, Atek Bantam #B424, 4' overall, 0-2 stroke, 48" between housing, 20 SPM, NEW

SPECIFICATIONS:
CAPACITY ------------------------- 24 TONS X 4 ft BED
STROKE --------------------------- 0 - 2
BED ADJUSTMENT ------------------- 3 in
WINDOW DEPTH --------------------- 6 in
WINDOW HEIGHT -------------------- 8 3/4 in
BED & RAM THICK ------------------ 1-3/4 in
RAM HEIGHT ----------------------- 13
BED WIDTH ------------------------ 48
BETWEEN HOUSINGS ----------------- 48 1/4
BACK GAUGE DEPTH ----------------- 0 TO 19 in BETWEEN HOUSINGS, 21 in BETWEEN CYCLINDERS
FULL STROKE FREE AIR ------------- 4.4 CFS
MAX. SPEED ----------------------- 20 SPM
TOOLING SPACE -------------------- 9 1/2 in
FLOOR SPACE (L-R X F-B) ---------- 5 ft X 2 1/2 ft
SHIPPING WEIGHT (APPROX.) -------- 2,835 LBS.
FEATURES:
- 4150 TOOL STEEL DIE SET CONSISTING OF A 90° TOP PUNCH AND 3/4 in BOTTOM DIE
- REMOVABLE DIE HOLDER, ACCEPTS AMERICAN STYLE TOOLING
- COMPLETE MODULAR FRL UNIT WITH OSHA LOCKOUT
- SAFETY HOODED FOOT PEDAL WITH TOE FLIP COVER
- TAMPER-PR
EQUIPPED WITH:
- PEDESTAL MOUNTED CONTROL
- GAUGE ASSEMBLY
- (2) FLIP FINGER ASSEMBLIES
- RAM MICRO SWITCH
- ONE CALIBRATION TOOL
- ONE INSTALLATION/OWNER'S MANUAL
- SPECIFY ENGLISH OR METRIC
- SPECIFY INPUT POWER VOLTAGE
NOTES:
SPECIFICATIONS SUBJECT TO VERIFICATION
OPTIONAL FEATURES:
FLOOR STAND (BST424) ------------------------- $ 1,400.00
DELIVERY:
SUBJECT TO STOCK
