kVA: 2200
Primary: 33000
Secondary: 420
Stock # 196772
1 / 3
Click to zoom in
1 / 3
For Sale by Savona Equipment
Surplus Record Dealer Since 2026
Location: Savona, BC Canada
Contact Sales Dept.
Phone Number: 250...> Show Phone Number 250-800-9179
Let the seller know you found their listing on Surplus Record!
Description
Specifications
- General Data:
- Power Rating: 2200 KVA.
- Primary Voltage: 33 kV.
- Secondary Voltage: 420 V.
- Tappings: ±2,5±5 %.
- Vector Group: Dyn11.
- Frequency: 50 Hz.
- Cooling: ONAN.
- Ambient T /Av. Winding T rise / Oil T rise 40°C / 65 K / 60 K.
- Insulation Levels HV (Vmax / LI / AC) 36 / 170 / 70 KV.
- Insulation Levels LV (Vmax / LI / AC) 1,1 / 20 / 10 KV.
- Material: HV/LV Aluminum / Aluminum.
- Standards: IEC 60076-1.
- (UE) N°548/2014.
- Electrical Data
- No-load losses: 1800 W.
- Load losses to 75°C: 21600 W.
- Short-circuit voltage to 75°C 6 %.
- Sound power Lw(A): 61 dB(A).
- Approximate Dimensions & Weight
- Length 2490 mm.
- Width 1560 mm.
- High 2450 mm.
- Total weight 6650 Kg.
Get Your Price from Savona Equipment!
