For Sale by Revelation Machinery
Surplus Record Dealer Since 2017
Location: Chicago, IL
Contact Tim Wheeler
Phone Number: 816...> Show Phone Number 816-330-2138
Let the seller know you found their listing on Surplus Record!
Description
Make: US Industrial
Model: USHB22-4
Year: 2008
Machine Location: California
Model: USHB22-4
Year: 2008
Machine Location: California
Working Pressure: 22 Tons
Length of Working Table: 51.9”
Distance Between Housings: 40.1″
Throat Depth: 7.8”
Stroke Adjustment of Ram: 2.75”
Ram Travel: 3.14”
Open Height: 9.64”
Rapid Ram Travel Speed: 2.4”/sec.
Rapid Ram Retreat Speed: 2.0”/sec
Motor Horsepower: 7.5 HP
Machine Weight: 4,500 LBS
Equipped With:
Backgauge
Foot Pedal
Get Your Price from Revelation Machinery!
