For Sale by Wheeler Machinery Sales
Surplus Record Dealer Since 1998
Location: Pomona, CA
Contact Dan Wheeler
Phone Number: 909...> Show Phone Number 909-348-5610
Let the seller know you found their listing on Surplus Record!
$3,185,000 USD
Description
Machine Standard Features and Equipment:
Made in Taiwan
Meehanite casting high performance cast iron
ISO 9001 certified
Large spindle bore 3-1/8
Heavy Duty spindle D1-8
Heavy Duty guideway width 12
Spindle speeds from 40-2,000 rpm, 12 speeds
Threading and feeding rate change without changing gears
Spindle is balanced, hardened and precision ground
Spindle is supported at 3-point by high precision bearings
All gears and shafts are hardened and precision ground
Guideways induction hardened and precision ground
Automatic lubrication system in headstock and feed box
One year industrial warranty for parts
Standard Equipment (free) for Lathes # GML-2160T & GML-2190T:
Free CARMAR DRO, installed
Automatic kick-out longitudinal carriage stop system
10 3-jaw chuck with top reversible jaws, direct mount
16 Face plate
9 steady rest with roller jaws
4 follow rest with roller jaws
Removeable gap
4-way tools post
Foot brake
LED Work light
coolant system
full length rear splash guard
Dead centers
Thread chasing dial
Reducing sleeve MT6/MT5 for spindle
Tool box and leveling pads
Specifications
GML-2160T
Max. swing over bed 20-1/2
Max. length of workpiece 60
Max. swing over cross slide 13"
Max. Swing in gap 29-1/8
Width of Bed 12
Effective length in gap to spindle 6
Effective length in gap to chuck jaws 3-1/2
Spindle bore 3-1/8 , D1-8
Taper of spindle center M.T.# 6 w/ reducing sleeve MT6/MT5
Spindle speeds 40-2,000 rpm / 12 steps
Longitudinal feeds 0.002-0.03 IPR, 35 kinds
Cross feeds 0.0008-0.011 IPR, 35 kinds
Inch threads 4-56 TPI, 36 kinds
Metric threads 0.5-7.0 mm ,17 kinds
Max. travel of top slide 5
Max. travel of cross slide 11
Spindle length w/o chuck 17
Leadscrew length X TPI 1-1/4 x 4 TPI
Diameter of tailstock quill 2-3/4
Max. travel of tailstock quill 5-7/8
Taper of tailstock quill center M.T. #4
Main motor 7-1/2HP, 220V or 440V, 3 phase
Amperage Draw 220V/ 35A , 440V/20A
Coolant pump motor
1/8 HP, 220V, or 440V, 3 phase, 2Gal coolant
Machine Oil
# 30 weight Machine oil, 5 Gallons
Machine weight, approx. LBS 4,150 LBS
Overall dimensions, LxWxH
Shipping dimensions: LxWxH
105 x 41 x 59
139 x 41 x 59
Made in Taiwan
Meehanite casting high performance cast iron
ISO 9001 certified
Large spindle bore 3-1/8
Heavy Duty spindle D1-8
Heavy Duty guideway width 12
Spindle speeds from 40-2,000 rpm, 12 speeds
Threading and feeding rate change without changing gears
Spindle is balanced, hardened and precision ground
Spindle is supported at 3-point by high precision bearings
All gears and shafts are hardened and precision ground
Guideways induction hardened and precision ground
Automatic lubrication system in headstock and feed box
One year industrial warranty for parts
Standard Equipment (free) for Lathes # GML-2160T & GML-2190T:
Free CARMAR DRO, installed
Automatic kick-out longitudinal carriage stop system
10 3-jaw chuck with top reversible jaws, direct mount
16 Face plate
9 steady rest with roller jaws
4 follow rest with roller jaws
Removeable gap
4-way tools post
Foot brake
LED Work light
coolant system
full length rear splash guard
Dead centers
Thread chasing dial
Reducing sleeve MT6/MT5 for spindle
Tool box and leveling pads
Specifications
GML-2160T
Max. swing over bed 20-1/2
Max. length of workpiece 60
Max. swing over cross slide 13"
Max. Swing in gap 29-1/8
Width of Bed 12
Effective length in gap to spindle 6
Effective length in gap to chuck jaws 3-1/2
Spindle bore 3-1/8 , D1-8
Taper of spindle center M.T.# 6 w/ reducing sleeve MT6/MT5
Spindle speeds 40-2,000 rpm / 12 steps
Longitudinal feeds 0.002-0.03 IPR, 35 kinds
Cross feeds 0.0008-0.011 IPR, 35 kinds
Inch threads 4-56 TPI, 36 kinds
Metric threads 0.5-7.0 mm ,17 kinds
Max. travel of top slide 5
Max. travel of cross slide 11
Spindle length w/o chuck 17
Leadscrew length X TPI 1-1/4 x 4 TPI
Diameter of tailstock quill 2-3/4
Max. travel of tailstock quill 5-7/8
Taper of tailstock quill center M.T. #4
Main motor 7-1/2HP, 220V or 440V, 3 phase
Amperage Draw 220V/ 35A , 440V/20A
Coolant pump motor
1/8 HP, 220V, or 440V, 3 phase, 2Gal coolant
Machine Oil
# 30 weight Machine oil, 5 Gallons
Machine weight, approx. LBS 4,150 LBS
Overall dimensions, LxWxH
Shipping dimensions: LxWxH
105 x 41 x 59
139 x 41 x 59
Inquire Further with Wheeler Machinery Sales!
