Description
Specifications | |||
|---|---|---|---|
| Tonnage | 200 | ||
| Stroke | 7.87 inches | ||
| Shut Height | 28.6 inches | ||
| Adjustment | 5.9 inches | ||
| Bed Size | 61" LR x 37.4" FB | ||
| Ram Area | 61" LR x 32.6" FB | ||
| SPM | 40-80 VSPM | ||
Standard Specifications Used Aida PMX-L2-200(1) Serial Number 12902-0240 Progressive Die Link Drive Stamping Press 200 ton Metric Capacity220 ton US Capacity 7.87" Stroke 19.6" Die Height Over Bolster 28.6" Shut Height Over Bed 5.9" Adjustment 61" LR x 37.4" Bed Area 61" LR x 32.6" Slide Area 40-80 VSPM Equipment and Features Air Clutch and Brake Progressive Link Motion Drive - Reduces Snap-through - Increases Time in the Forming Portion of Stroke Dynamic Slide Balancing Automatic Recirculating Lube System Hydraulic Overload Protection 38" Floor To Top of Bolster 8-Point Oil Film Slide Guide System Micro Inch Capability 40 HP Main Motor, 460V 60HZ 11.8" Thick T-Slotted Bolster T-Stand Palm Buttons 33.5" Wide Windows Safety Doors Front and Back Flush Floor Standing Weight 79,360 lbs. Overall Height: 16' 10" Tall Shipping Dimension: 9' 8.5" Wide This Used 200-ton Aida PMX Press can be seen underpower in the S&G Press Livonia Michigan Warehouse. Click for more Aida Press Options The 200-ton Aida PMX Press delivers precise control throughout the stroke and maximizes material flow in the forming zone, ensuring consistent quality in metal stamping. Its durable build reduces downtime and maintenance costs, while high-speed operation enhances productivity, meeting deadlines efficiently. Versatile for progressive stampings, forming, and blanking operations, it's an ideal choice. Aida Link Drive Mechanical Metal Stamping Press For Sale | |||
