20" Schunk 3-jaw extended stroke air chuck, 8" hole, 1" travel per jaw, excellent cond

Manufacturer Schunk
Size of Chuck 20.000"

For Sale by HTR Inc.

Silver Level Dealer
Surplus Record Dealer Since 1998

Description

SCHUNK TB-LH 500-205 AIR CHUCK
Schunk part number0818015
Serial number083607
Chuck diameter500 mm (19.68")
Thru hole205 mm (8.07 ")
Spindle noseflat back
Stroke per jaw0.66" rapid, 0.33" clamping
Total stroke per jaw1"
Jaw serrations3/32 x 90'
Maximum rpm1,100 rpm
Maximum clamping force240 kN @ 85 psi.
Weight without top jaw tooling748 lbs.
Included with the chuck: Air distributor ring.

Condition: Very good to excellent. 30 day return.
Delivery: Stock, our warehouse.
Mounting package:
--We can also supply a full wrap around distributor ring mounting bracket (DRMB) for a front mounted chuck or stand-off brackets for a rear mounted chuck. We also supply adapter plates and can do the complete installation if required.
