20" x 12" Kent USA #VB-2012H/2012HE, vertical band saw, 3 HP, digital read out tachometer, blade welder/ginder/shear, new

Manufacturer: Kent
Max Throat or Width: 20.00
Max Height / Under Guide: 12.00
Stock # 19013

For Sale by Blumberg Machinery Co

Platinum Level Dealer
Surplus Record Dealer Since 1971
  Jerry/ Ryan
  847-58...> Show Seller's Phone Number 847-580-6800 Let the seller know you found their listing on Surplus Record!

Description

NEW - 20" KENT USA MODEL VB-2012H/2012HE VERTICAL BAND SAW


OUTSTANDING FEATURES:

l 3 HP main spindle motor

l Key Switch/Emergency stop switch

l Digital readout tachometer

l Blade welder/grinder/shear

l Work light

l Rip fence

l Upper wheel tilt adjuster blade tension indicator

l Chip Blower

l Post elevating handwheel

Model

VB-2012H

VB-2012HE

Machine Capacity

Max. throat capacity

20” (508mm)

Max. work height

12” (305mm)

Wheel Diameter

20.25”x2 (515mm x2)

Blade Speed

Low:15-125 M/min HI:165-1500 M/min

(Low:50-415 M/min HI:550-5000 F/min)

Blade Size

1” x 0.035” x 130”(27 x 0.9 x 3300 mm)

Blade

Max. Length

158.75”(4035mm)

Max. width

1”(27mm)

Welder capacity

0.75”(19mm)

Motor

Saw

3 HP(2.2 kw)(3 phase)

Table

Size

23.5”x27.5”(600x700mm)

Tilt

R:45 Deg. L:10 Deg.

Height

40”(1016mm)

Feed power

80kg/cm, 110V

Stroke

12”(300mm)

Weight

Net

1,298 lbs

(590kgs)

1,375 lbs

(625kgs)

Shipping Dimensions

43” x 32” x 80”(1090x810x2030mm)
