Click to zoom in
For Sale by Smith Machinery Co
Surplus Record Dealer Since 2001
Location: Ames, IA
Contact Jim Smith
Phone Number: 515...> Show Phone Number 515-233-6330
Let the seller know you found their listing on Surplus Record!
Description
Specifications
Equipped With
Equipped With
| Tube (Min.) | .25 inches |
| Tube (Max.) | 2 inches |
| Pipe (Max.) | 1.5" - Sch. 40 |
| Centerline Radius (Min.) | 2 x |
| Centerline Radius (Max.) | 8.875 inches |
| Degree of Bend | 0-210 |
| Bending Speed | 2 RPM |
| Programming | One touch bend angle control with spring back |
| Material Positioning Table | yes |
| Voltage | 220V 1ph |
| Dimensions (L x W x H) | 22.5" x 16.25" x 39.5" |
| Weight | 300 pounds |
Equipped With
Equipped With
FEATURES:
SB48 Bending Capacities
OPTIONAL FEATURES:
* Center Former 67MM (2.6") CLR 1" Pipe: $660.00
* Counterbend Die Bronze, 1" Pipe: $310.00
* Center Former 100MM (3.9") CLR 1-1/2" Pipe: $930.00
* Counterbend Die Bronze, 1-1/2" Pipe: $320.00
* Ercolina Grease - 1 Can: $39.00
DELIVERY:
50% DOWN, PAYMENT IN FULL PRIOR TO SHIPMENT
SB48 Bending Capacities
Material Type | Maximum Diameter | Maximum Wall Thickness
Pipe | 1.500 pipe | SCH 40
Mild steel tube | 2.000 | 0.140
Soft brass | 1.875 | 0.120
Stainless steel | 1.875 | 0.065
Hydraulic tube | 2.000 | 0.120
Hard copper & aluminum - 2.000 | 0.065
Round solids | 1.250 | NA
Rectangular solids - 0.312 x 1.875 | NA
Rectangular tube - 0.750 x 1.625 | 0.120
Square tube | 1.5 x 1.5 | 0.120
Solid square | 1.250 x 1.250 | NA
* Mild steel tube capacity 2″
* Pipe capacity 1-1/2″ Sch. 40
* Square tube capacity 1-1/2″ .083 wall
* Maximum CLR 8-7/8″
* Bend to CLR as small as 2D
* Easy one touch control allows any operator to program and automatically store bend angle.
* Large easy to read color coded control displays all current information in real time.
* Separate display of material spring back for greater accuracy on a variety of materials.
* Bend any angle to 180° with independent material springback compensation for each bend.
* Single Bending Speed.
* Inititate bend cycle from the control panel or included foot petal.
* Quick-change tooling system with multiple radi available.
* Swing away counterbending die vise for easy material handling.
* Accepts Ercolina's A40-P two axis positioning table for multiple and sequential bends.
* Classic Ercolina design reduces floor space requirement and easily stores to save shop floor space.
* NO Hydraulic components.
NOTES:
SPECIFICATIONS SUBJECT TO VERFICATION* Mild steel tube capacity 2″
* Pipe capacity 1-1/2″ Sch. 40
* Square tube capacity 1-1/2″ .083 wall
* Maximum CLR 8-7/8″
* Bend to CLR as small as 2D
* Easy one touch control allows any operator to program and automatically store bend angle.
* Large easy to read color coded control displays all current information in real time.
* Separate display of material spring back for greater accuracy on a variety of materials.
* Bend any angle to 180° with independent material springback compensation for each bend.
* Single Bending Speed.
* Inititate bend cycle from the control panel or included foot petal.
* Quick-change tooling system with multiple radi available.
* Swing away counterbending die vise for easy material handling.
* Accepts Ercolina's A40-P two axis positioning table for multiple and sequential bends.
* Classic Ercolina design reduces floor space requirement and easily stores to save shop floor space.
* NO Hydraulic components.
NOTES:
OPTIONAL FEATURES:
* Center Former 67MM (2.6") CLR 1" Pipe: $660.00
* Counterbend Die Bronze, 1" Pipe: $310.00
* Center Former 100MM (3.9") CLR 1-1/2" Pipe: $930.00
* Counterbend Die Bronze, 1-1/2" Pipe: $320.00
* Ercolina Grease - 1 Can: $39.00
DELIVERY:
50% DOWN, PAYMENT IN FULL PRIOR TO SHIPMENT
