1500 KVA 34500 Delta Primary, 480Y/277 Secondary, IEN Hanchang, 7-Tap, 150kV BIL, DOE 2016, UL Listed, New (In-Stock)

🚀 Ready-to-Ship! Contact us now to receive the As-Built Drawings and Test Reports immediately

This premium 1500 kVA three-phase pad-mounted transformer is manufactured by HC Transformer & Switchgear (IEN Hanchang). Designed for high-end utility and heavy industrial applications, this unit features an ultra-high-voltage 34,500V Delta primary with a superior 150kV BIL insulation rating.

It is UL Listed and fully compliant with 2016 DOE efficiency standards. Currently in stock and ready for immediate loading with full documentation.

• Capacity : 1500 kVA (Three-Phase, 60Hz, ONAN)

• Voltage : 34,500V Delta primary to 480Y/277V


• Insulation Level : 150 kV BIL (HV) / 30 kV BIL (LV) — Advanced Surge Protection


• Protection System : 38kV-Class Dual Fusing – Bay-O-Net + Current Limiting Fuse

• Tap Changer : 7-Position De-energized Tap Changer (DETC) – Range: 26.4kV to 20.2kV

• Vector Group : Dyn1 (Optimized for grounding & harmonic mitigation)

• Switching : Cooper 4-Position Loadbreak T-Blade Switch

• Efficiency: Fully compliant with DOE 2016 Standard



Detailed Specifications

🌟 Why HC TNS? (Your Trusted Power Partner)

Beyond just a sale—Integrated solutions for your project’s success.

• [Ready-to-Ship] Immediate delivery from our extensive stock (300 kVA – 3,750 kVA).

• [Fast-Track] Custom-built units with the industry’s shortest lead times for your specific requirements.

• [Professional] Expert on-site installation and emergency repair services provided by senior engineers.

• [Proven Quality] Over 50 years of U.S. electric expertise, specializing in high-reliability pad-mounted designs and UL Listed (E362009) compliance.

Inquire today for 7-Tap specifications and the fastest delivery schedule!
