Manufacturer: Grundfos
Model: CR3-19 K-FGJ-A-E-HQQE
Gallons per Minute: 15
TDH': 455
Model/Size: CR3-19 K-FGJ-A-E-HQQE
Stock # 106775
Price: $2,301 USD
1 / 4
Click to zoom in
1 / 4
For Sale by Lenmark Industries
Surplus Record Dealer Since 2024
Location: Langley, BC Canada
Contact Lenmark Sales
Phone Number: 778...> Show Phone Number 778-653-5801
Let the seller know you found their listing on Surplus Record!
$2,301 USD
Description
SKU: 106775
Model: CR3-19 K-FGJ-A-E-HQQE
Condition: Used
General Specifications:
Horsepower: 5 hp
GPM: 15.4
Pump Material: Cast Iron
PSI: 363
Head: 455 ft
RPM: 3461 rpm
Electrical Specifications:
Voltage: 230/460 volts
Phase: 3-phase
Made In: UNITED STATES
Dimensions: 40.00 (H) x 10.00 (W) x 10.00 (L) inches
Additional Description:
Series: CR
Model: CR3-19 K-FGJ-A-E-HQQE
Part Number: 91128593
Pump Code: P11938
Pump Type: Vertical Multistage Centrifugal
Motor Power: 5 HP (3.7 kW)
Motor Efficiency: IE3 Premium Efficiency
Frequency: 60 Hz
Voltage: 208-230/460 VAC, 3-Phase
Current: 14.1-13.1 / 7.29 A
Maximum Current: 16.2-15.0 / 8.40 A
Service Factor: 1.15
Motor Speed: 3525-3540 RPM
Pump Speed: 3461 RPM
Rated Flow: 15.4 GPM
Rated Head: 455 ft
Maximum Head: 600 ft
Maximum Pressure: 363 PSI
Maximum Temperature: 248F
Connection Size: 1-1/4 in ANSI Flanged (Inlet & Outlet)
Rotation: Counter Clockwise (CCW)
Motor Enclosure: TEFC
Protection: IP55
Insulation Class: F
Ambient Rating: 60C Continuous Duty
Weight (Motor): 40 kg
Motor Frame: 182TC
Bearings: DE 7308BE.2CS / NDE 6206.2Z.C3
Certification: UL, CE, NSF/ANSI 61 & 372
Country of Assembly: USA
Motor Origin: Hungary
Ideal Applications
- Pressure boosting systems
- Commercial buildings
- Municipal water systems
- Reverse osmosis systems
- Water treatment plants
- Industrial process water
- Boiler feed systems
- Cooling water circulation
- Irrigation systems
- Potable water distribution
Model: CR3-19 K-FGJ-A-E-HQQE
Condition: Used
General Specifications:
Horsepower: 5 hp
GPM: 15.4
Pump Material: Cast Iron
PSI: 363
Head: 455 ft
RPM: 3461 rpm
Electrical Specifications:
Voltage: 230/460 volts
Phase: 3-phase
Made In: UNITED STATES
Dimensions: 40.00 (H) x 10.00 (W) x 10.00 (L) inches
Additional Description:
Series: CR
Model: CR3-19 K-FGJ-A-E-HQQE
Part Number: 91128593
Pump Code: P11938
Pump Type: Vertical Multistage Centrifugal
Motor Power: 5 HP (3.7 kW)
Motor Efficiency: IE3 Premium Efficiency
Frequency: 60 Hz
Voltage: 208-230/460 VAC, 3-Phase
Current: 14.1-13.1 / 7.29 A
Maximum Current: 16.2-15.0 / 8.40 A
Service Factor: 1.15
Motor Speed: 3525-3540 RPM
Pump Speed: 3461 RPM
Rated Flow: 15.4 GPM
Rated Head: 455 ft
Maximum Head: 600 ft
Maximum Pressure: 363 PSI
Maximum Temperature: 248F
Connection Size: 1-1/4 in ANSI Flanged (Inlet & Outlet)
Rotation: Counter Clockwise (CCW)
Motor Enclosure: TEFC
Protection: IP55
Insulation Class: F
Ambient Rating: 60C Continuous Duty
Weight (Motor): 40 kg
Motor Frame: 182TC
Bearings: DE 7308BE.2CS / NDE 6206.2Z.C3
Certification: UL, CE, NSF/ANSI 61 & 372
Country of Assembly: USA
Motor Origin: Hungary
Ideal Applications
- Pressure boosting systems
- Commercial buildings
- Municipal water systems
- Reverse osmosis systems
- Water treatment plants
- Industrial process water
- Boiler feed systems
- Cooling water circulation
- Irrigation systems
- Potable water distribution
Inquire Further with Lenmark Industries!
