Manufacturer: Mvd
Model: B135-3100
Year: 2026
Tons: 135.0
Overall: 1.1
Stock # 155255
Price: $116,224 USD
1 / 2
Click to zoom in
1 / 2
For Sale by Lenmark Industries
Surplus Record Dealer Since 2024
Location: Langley, BC Canada
Contact Lenmark Sales
Phone Number: 778...> Show Phone Number 778-653-5801
Let the seller know you found their listing on Surplus Record!
$116,224 USD
Finance for as low as $2,357/mth
Description
SKU: 155255
Model: B135-3100
Year: 2026
Condition: New
General Specifications:
Bed Length: 3100 mm
Tons: 135 ton
Brake Type: Hydraulic
CNC: Yes
Made In: TURKEY
Additional Description:
Features:
- Y1, Y2, X+R (4 axis with X=750mm)
- CNC unit Delem DA-66S, 24" Touch Screen, 2D Graphical, (3-8 axis)
- Stroke 260mm & Throat depth 410 mm
- MVD Servo motorised backgauge with ball screws, linear guided, Mitsubishi/LS/Delta Motors&Drivers
- CNC Controlled Type#1 Crowning (by MVD wedges and GEC motor)
- GIVI (Italy) Optic Linear Scales
- 2 Pieces backgauge fingers, manually movable along the linear guide, precisely adjusted
- Side safety doors and cylinder covers
- HAWE=Hoerbiger (Germany) hydraulic blocks with proportional valves
- Eckerle (Germany) oil pump, internal gear type
- M-EASY Manual Promecam ES4389/Z1 (vertical removal/insertion)
- Narrow Bottom table (MVD Special design) IW = 60mm+10mm spacer (F<= 270Tons) IW=90mm (F>=320 ton)
- Sliding Front support arms (2pcs)
- Top Tool : Eurostamp 1260, H:67, 85, R:0,8
- Bottom Die : Eurostamp 2067, 4 way V=16-22-35-50mm, 85, H:60
- AKAS(FPBS) front safety lasers + rear light beams
- Set-up and Training
- 1 Year Warranty
Dimensions (L x W x H): 4690 x 2340 x 2980 mm
Total Weight (approx): 7750 kg
Model: B135-3100
Year: 2026
Condition: New
General Specifications:
Bed Length: 3100 mm
Tons: 135 ton
Brake Type: Hydraulic
CNC: Yes
Made In: TURKEY
Additional Description:
Features:
- Y1, Y2, X+R (4 axis with X=750mm)
- CNC unit Delem DA-66S, 24" Touch Screen, 2D Graphical, (3-8 axis)
- Stroke 260mm & Throat depth 410 mm
- MVD Servo motorised backgauge with ball screws, linear guided, Mitsubishi/LS/Delta Motors&Drivers
- CNC Controlled Type#1 Crowning (by MVD wedges and GEC motor)
- GIVI (Italy) Optic Linear Scales
- 2 Pieces backgauge fingers, manually movable along the linear guide, precisely adjusted
- Side safety doors and cylinder covers
- HAWE=Hoerbiger (Germany) hydraulic blocks with proportional valves
- Eckerle (Germany) oil pump, internal gear type
- M-EASY Manual Promecam ES4389/Z1 (vertical removal/insertion)
- Narrow Bottom table (MVD Special design) IW = 60mm+10mm spacer (F<= 270Tons) IW=90mm (F>=320 ton)
- Sliding Front support arms (2pcs)
- Top Tool : Eurostamp 1260, H:67, 85, R:0,8
- Bottom Die : Eurostamp 2067, 4 way V=16-22-35-50mm, 85, H:60
- AKAS(FPBS) front safety lasers + rear light beams
- Set-up and Training
- 1 Year Warranty
Dimensions (L x W x H): 4690 x 2340 x 2980 mm
Total Weight (approx): 7750 kg
Inquire Further with Lenmark Industries!
