Description
Description
Hardinge 11″ x 18″ Super Precision Toolroom Lathe, HLV-H
Inventory # 10067
Model: HLV-H
S/N: HLV-H-6110
Specifications:
Swing Over Bed: 11″
Swing Over Carriage: 9″
Swing Over Cross Slide: 6″
Distance Between Centers: 18″
Spindle:
Hole Through Spindle: 1 1/4″
Spindle Nose: Hardinge Tapered
Spindle Speeds: 125 – 3,000 RPM
Compound Slide Travel: 3″
Powerfeed Range: 1/4″ – 7″ per Min.
Tailstock:
Tailstock Diameter: 1 3/8″
Tailstock Travel: 3 3/4″
Lead Screw Diameter: 1″ – 8″ Thread
Motor: 3 HP / 230v, 460v / 3ph
Mechanical Specifications:
Dimensions: 72″ x 33″ x 60″ H
Weight: approx. 1,700 lbs.
FOB Our Baltimore, MD Warehouse
