Description
10" x 18" Cincinnati Plain Cylindrical Grinder, Model 430 DA, 36" x 9 1/2" Grinding Wheel, Plunge, 15 HP Motor, Seperate Electrics & Hydraulics, As Is.
430-10CINCINNATIEC PLUNGE GRINDER
S/N35432A980-0002 Year:1980
STANDARD SPECIFICATIONS
Work Piece Capacity
Nominal work piece diameter………………………………………… 10
Actual swing diameter over table..…………………………..……….. 10.93
Nominal work piece length………………………………..………….. 18
Actual work piece length………………………………..………….…. 20
Maximum Work Piece Weight
Hydraulic type footstock…………………………………………….. 350 lbs.
Wheel Head
Grinding wheel diameter(new)………………………………………. 36
Grinding wheel diameter(worn)……………………………………… 24
Collet hole diameter……………………………….………………….. 20
Grinding wheel width……………………………………………….… 9 1/2
Grinding wheel speed (opt.)surface motor……………..………..…… 8500 ft./min25 HP
Sliding Table
Max. work piece length……………………………..……………..….. 20
Total table traverse/rev. ofhex wrench……………………………..… 1
Swivel Table
Nominal work piece length………………………………………….... 18
Maximum swivel counterclockwise……………..……………………. 11'
Maximum swivel clockwise…………………………………………... 3'
Taper (maximum on diameter)per foot……….………………………. 4.67
Head Stock
Work piece center…………………………………………….. No. 14 Jarno
Head stock spindle – standard A.C. motor………...….……… 34, 49, 100, 144, 206RPM
Motor –A.C…………………………………………………... 1 HP
Spindle nose (optional)live…………………………………... Type A-1 size 6
Foot Stock
Work piece center……………………………………………... No. 14 Jarno
Center movement – hydraulic type…………………….………. 2
EQUIPMENTANDFEATURES
Behind wheel hydraulic profile truing.
Auto balancing grinding wheel spindle.
8500 Surface feet per minute.
Hydraulic tail stock.
Free standing, 2 door electrical panel.
Separate, external hydraulic unit.
Specifications are deemed accurate, however, subject to verification or prior sale.
All exchange units/returns must be shipped within 30 days. All exchange units/returns must be shipped using DDP terms - Grinders Clearing House, Inc. dba GCH Machinery, is not responsible for any customs formalities or shipping costs.
If Grinders Clearing House, Inc. dba GCH Machinery does not receive exchange/core unit back within30 days, GCH will invoice FULL replacement cost (OUTRIGHT Cost) to customer.
430-10CINCINNATIEC PLUNGE GRINDER
S/N35432A980-0002 Year:1980
STANDARD SPECIFICATIONS
Work Piece Capacity
Nominal work piece diameter………………………………………… 10
Actual swing diameter over table..…………………………..……….. 10.93
Nominal work piece length………………………………..………….. 18
Actual work piece length………………………………..………….…. 20
Maximum Work Piece Weight
Hydraulic type footstock…………………………………………….. 350 lbs.
Wheel Head
Grinding wheel diameter(new)………………………………………. 36
Grinding wheel diameter(worn)……………………………………… 24
Collet hole diameter……………………………….………………….. 20
Grinding wheel width……………………………………………….… 9 1/2
Grinding wheel speed (opt.)surface motor……………..………..…… 8500 ft./min25 HP
Sliding Table
Max. work piece length……………………………..……………..….. 20
Total table traverse/rev. ofhex wrench……………………………..… 1
Swivel Table
Nominal work piece length………………………………………….... 18
Maximum swivel counterclockwise……………..……………………. 11'
Maximum swivel clockwise…………………………………………... 3'
Taper (maximum on diameter)per foot……….………………………. 4.67
Head Stock
Work piece center…………………………………………….. No. 14 Jarno
Head stock spindle – standard A.C. motor………...….……… 34, 49, 100, 144, 206RPM
Motor –A.C…………………………………………………... 1 HP
Spindle nose (optional)live…………………………………... Type A-1 size 6
Foot Stock
Work piece center……………………………………………... No. 14 Jarno
Center movement – hydraulic type…………………….………. 2
EQUIPMENTANDFEATURES
Behind wheel hydraulic profile truing.
Auto balancing grinding wheel spindle.
8500 Surface feet per minute.
Hydraulic tail stock.
Free standing, 2 door electrical panel.
Separate, external hydraulic unit.
Specifications are deemed accurate, however, subject to verification or prior sale.
All exchange units/returns must be shipped within 30 days. All exchange units/returns must be shipped using DDP terms - Grinders Clearing House, Inc. dba GCH Machinery, is not responsible for any customs formalities or shipping costs.
If Grinders Clearing House, Inc. dba GCH Machinery does not receive exchange/core unit back within30 days, GCH will invoice FULL replacement cost (OUTRIGHT Cost) to customer.
