0.3 HP Lenze #SM004S, VFD, 100-120V AC Input, 0-230V AC Output, 0.25 KW, 1.4 A, IP20

$1,184 USD

Request Formal Quote

THE LENZE SM004S IS A VARIABLE FREQUENCY DRIVE (VFD) DESIGNED FOR MOTOR CONTROL APPLICATIONS. IT OPERATES ON A SINGLE-PHASE 100-120V AC INPUT AT 50/60HZ. THE DRIVE DELIVERS A THREE-PHASE OUTPUT RANGING FROM 0 TO 230V AC WITH A MAXIMUM OUTPUT FREQUENCY OF 240 HZ. IT IS RATED FOR 0.25 KW (0.33 HP) AND PROVIDES A CONTINUOUS OUTPUT CURRENT OF 1.4 A. KEY OPERATIONAL FEATURES INCLUDE 150% OVERLOAD CAPACITY FOR 60 SECONDS AND SUPPORT FOR SENSORLESS VECTOR OR V/HZ CONTROL METHODS. THE UNIT FEATURES AN IP20 ENCLOSURE RATING AND INTEGRATES RS485 MODBUS RTU COMMUNICATION CAPABILITIES.
