44" wide belt, 3/16" to 4" thick pieces, Belt Speed: 52.5 ft./sec. (16 m/s), Grinding Belt dimension: 44" x 84.5" (1120 X 2150 mm ), Main Motor: 25 Hp + 5.5 Hp (18.5 + 4 kW), Drive feet: 1.8 Hp (3.3-33 ft./min.), 1.3 kW (1-10 m/min), Drive high adjustment motor: 3/4 Hp (0.55 kW), Conveyor Belt dimension: 43" x 118" ...more

Bevel Angles 25-55 Degrees, Max. Capacity 1" Bevel width x 2" Plate thickness, Min. Land (Unbeveled Edge) 1/8", Adjustable Guide Rolls, Power adjustment Bevel angles, Pendent controls, 144" x 60" Roller Ball table, Crane attachment, With 480 Volt Transformer.

15.74" (400 mm ) Saw blade, 5.11" (130 mm) Cutting Diameter, 5.11" (130 mm) Capacity 45 Degree: Round, 6.29" x 35.0" (160 x 890 mm) Capacity 45 Degrees: Flat, 5.11" (130 mm) Capacity 90 Degrees: Round, 8.26" x 3.14" (210 x 80 mm) Capacity Degrees: Flat, 3.54" (90 mm) Capacity 60 Degrees: Round, 4.13" x 3.14" (105 x 80 ...more

15" x 96" Working Surface of Table, 6' of Table Travel, 10" Vertical Adjustment Spindle Carrier, 11" Center Line Table to Spindle Carrier, Top of Table to Center Line Spindle 14" Max. / 4" Min., 3" Quill Adjustment, NO. 50 NST Spindle Tapers, 50 - 3000 RPM (16) Speed Range, 1 - 150 IPM (infinite) Feed Range, 300 ...more

Principal :, PRESSING FORCE-MAIN SLIDE, 500 Ton full tonnage pressing, 100 Ton low tonnage pressing, 55" Ton return capacity @ 3500 P.S.I., 17" Diameter main ram diameter (single acting), 6-4" Closing & return rams (double acting)**, 3537 PSI System pressure, **By selector switch setting closing rams only using ...more

Width: 72", Length: 144", Thickness of Top Plate: 6.5", Height of Plate on Stand: 24.5".

8" BELT WIDTH, SINGLE HEAD, 23" x 18" TABLE WITH HYDRAULIC LIFT, IDLER PULLEY, 30HP 230/460/60/3, PNEUMATIC IN-FEED ON TABLE, 108" LR x 70" FB x 80" TALL APPROXIMATE DIMENSIONS, 6000 LBS APPROXIMATE WEIGHT, REPLACEMENT COST $160,000, GOOD CONDITION.

Capacity: 1/2", Overall Length of Table: 12'2", Front Operated Power Back Gauge: 36", Gap: 16", Hydraulic Hold Downs: 15, Squaring Arm: 10', Transfer Balls in Table, Electric Foot Trip, Dual Voltage, 50 HP Motor, 230( 122 AMP) / 460 Volt Volt (61 Amp) draw.

Weight: No Attached ounces Grinding Wheel Speed RPM: No Attached Main Motor: No Attached Max Table Load: No Attached ounces Z-Axis Travel: No Attached inches Y-Axis Travel: No Attached inches X-Axis Travel: No Attached inches Chuck Size: No Attached Incremental Downfeed: No Attached Table-W: No Attached inches ...more

Dimensions: L44 x W30 x H75 Overall dimensions Weight: 980 pounds 10 Hp Two Stage Pump, 120 Gal Vertical Tank, 34.4 cfm @ 175 psi, Magnetic Starter, 460V, 3 Ph, Runs and builds air well., New oil and air filters.

, Spindle Motor: 15HP, 240/480 volt, wired for 480 operation, Range: 20" Diameter x 9" Vertical over Chuck, Chuck: 16" Diameter, Chuck Speeds: 15, 24, 41, 64 RPM, Grinding Wheel: None, Customer to supply Diamond Wheel, Grinding Wheel Speed: 1200 RPM, Feeds:.003 -.070 IPM, Automatic lube systems, Standard Coolant ...more

248 icfm @ 28 psi, 13.4 psi Max. Differential Pressure, 290 Max. Air Delivery at 4.4 psi, 293 (vac) (icfm) Max. intake at 6" Hg, 20 Hp motor, 2.5" Pipe connection, 38" x 31" 47"height overall dimension, 727 Lbs. weight, With Sound enclosure & Kaeser STC Wye Delta Start Control, Blower unit has NEVER been use.

Power: 47.5 horsepower CNC Control: No Attached Type of CNC Control: No Attached Dimensions: 40" x 28" x 67" height Weight: 1510 pounds Frequency Drive compressor, 45-215 acfm air capacity @ 125 psi, 35kW/47.5 Hp, 460 V/ 3 Ph / 60 Hz motor, Belt drive air-end and motor, Approx. 70969 total hours.

Rise & Fall, 26" x 96" Working Surface of Table, 72" Table Travel, 16 Available Spindle Speed (with proper change gears of 20-800 RPM), Hydraulic Table Feeds of 1-1/2" to 150" Per Minute, Power Rapid Traverse, Arbor Support, Overarm Support, #50 N.S Taper Spindle, Automatic Quill Retraction, Hardened Bed Ways ...more

26" swing over bed, 132" Between Centers, 32" swing x 9" Gap removable, 19" swing over carriage, Spindle rpm 18-720, 2" Spindle hole, 5 Morse Taper, Taper Attachment, Threading dial, 21" 4 - Jaw Chuck, 32" Face plate, (2)Steady Rest, Chip pans, 480 V / 3ph, Approx. Weight 7,000 lbs.

150 HP, 440 Volt 60 Hz, 171 AMP, 1775 RPM, 445T TEFC, AEFA Type, Weight 730 Lbs., 1.15 S.F., 6318/NU318 Bearings.

Table:, 25" Standard Diameter of Table, 35" maximum Swing, 1-175 Work Spindle RPM, 8"-A2 Work Spindle Nose, Vertical Slide:, 21" Standard Vertical Slide Stroke, 2-180 IPM Vertical Slide Traverse Rate, 4.5" Grinding Spindle Mounting Diameter (Cartridge Style), 0-45 Deg Vertical Slide Angle Adjustments (Left or ...more
